Kitronik USB LED Strip with Light Sensor

The Kitronik USB LED Strip with Light Sensor is designed for low-power lighting projects. It features an onboard light sensor ideal for night lights or desk illumination that activates the LEDs when ambient light levels drop. The sensor can be bypassed with a side-mounted 3-position switch to provide continuous lighting.

The strip is powered via USB (under 100mA) and includes 5 bright LEDs with a luminous intensity of approximately 8000mCd, a phototransistor light sensor, and a three-way switch for controlling the LED operation. The PCB measures approximately 50mm x 10mm x 4.5mm and features a mounting hole for easy installation. It also has GND and +5V pads for alternative power sources.

Features:

• Specifically designed for low-power lighting projects.
• Onboard light sensor ideal for night light applications.
• Side-mounted 3-position switch: On, Off, Sense.
• Powered via standard USB port (5V, under 100mA).
• 5 bright white LEDs with ~8000mCd luminous intensity.
• PCB dimensions: 50mm length, 10mm width, 4.5mm height.
• Mounting hole for easy installation.
• Includes GND and +5V pads for alternative power supplies.

Technical Specifications:

• Operational Supply: 5V via micro USB connector
• Forward Current: 90mA at 5V
• Number of LEDs: 5 White LEDs
• Luminous Intensity: ~8000mCd
• Colour Temperature: 6500K
• Mounting: Single M3 hole (3.3mm Diameter)

Contents:

• 1 x White USB LED Strip with Sensor

Dimensions:

• Length: 50mm
• Width: 10mm
• Height: 4.5mm

Additional USB lead and power supply are required separately.
