40-pin TFT Friend - FPC Breakout with LED Backlight Driver

This breakout board is designed for 'dot-clock' 40-pin TFT displays that require continuous clocking of RGB pixel data. It features a 40-pin Flex PCB (FPC) connector and a TPS61169-based backlight driver with adjustable current, allowing for easy breadboard use.

The backlight driver defaults to 25mA and can boost up to 24VDC for up to 7-LED strings. Users should consult their display datasheet for string configuration and can increase backlight current by shorting jumpers.

This product comes with one assembled and tested PCB; header and TFT display are not included. Compatible displays include 4.3" with touchscreen and 5.0" displays with or without touchscreen.

Note: No tutorial is provided; advanced users with microprocessors capable of dot-clock-type TFT support will find this breakout useful as a wiring tool.

• Dimensions: 25mm x 51mm x 4mm
• Weight: 6g
• Includes TPS61169-based backlight driver
• Adjustable backlight current (default 25mA)
• Compatible with 40-pin FPC TFT displays
• Eagle CAD PCB files and Fritzing object available

Revision History: As of April 15, 2025, updated boost converter chip from FAN5333 to TPS61169, and improved PCB silkscreen using Adafruit Pinguin.
