Adafruit 1.14" 240x135 Color Newxie TFT Display - ST7789

Say hello to our new Newxie 1.14" 240x135 Color TFT Display Boards– we think it's T-F-T errific! This ultra-compact 1.14" diagonal display offers glorious 240x135 high-resolution pixel color and is packed with RGB pixels for very small, high-density visuals.

The breakout board is designed for compact stacking on a 0.1" grid with a vertical arrangement inspired by old-school nixie tubes. It uses plain SPI (Clock, Data In, Chip Select, Data/Command) communication and features its own pixel-addressable frame buffer, suitable for use with microcontrollers including low memory and limited pins.

This 1.14" IPS display boasts excellent color fidelity up to 80 degrees off-axis in any direction. It uses the ST7789 TFT driver, and Adafruit offers an Arduino library and CircuitPython/Python support to easily draw pixels, lines, shapes, text, and bitmaps.

The display is minimalistic with only 7 pins required for control and backlight. Two rows of pre-soldered 7-pin right-angle headers provide mechanical stability and easy stacking. An ultra-low-dropout 3.3V regulator and a 3/5V level shifter are included, allowing compatibility with 3.3V or 5V logic such as Arduino, ESP32, RP2040, or Raspberry Pi.

Features:

• 1.14" diagonal TFT display with 240x135 16-bit full color pixels
• IPS technology for wide viewing angles
• Uses ST7789 TFT driver
• SPI communication with only 7 pins required
• Two rows of 7-pin right-angle headers for stacking and stability
• Onboard ultra-low-dropout 3.3V regulator and 3/5V level shifter
• Compatible with 3.3V and 5V logic systems
• Supported by Arduino and CircuitPython libraries

Technical Specifications:

• Display Size: 1.14" diagonal
• Resolution: 240 pixels x 135 pixels
• Color: 16-bit full color (RGB)
• Driver IC: ST7789
• Interface: SPI (Clock, Data In, Chip Select, Data/Command)
• Voltage: Supports both 3.3V and 5V logic
• Dimensions: Approximately 0.8" wide
